DIN 17100 St52 Steel_1.0570
發布者：admin發布時間：2020-11-28 02:25:27

1.0570 Material St52-3 Steel Equivalent, Properties Composition – DIN 17100


DIN 17100 St52 Steel現貨價格查詢

St52 steel (St52-3) is an unalloyed structural steel grade complies with DIN 17100: 1980, the designation has been discarded since 2004. According to German standard DIN 17100, St52 steel is divided into St52-3U (1.0553) and St52-3N (1.0570 material). St 52 material new designation is S355, St52-3 new name is S355J2 (1.0577), St52-3 U new designation is S355J0 (1.0553), and St52-3 N new name in EN 10025: 1993 is S355J2G3, DIN 17100 has been replaced by EN 10025-2: 2004.

St 52 Material Datasheet & Specification

The St 52 material datasheet and specification such as chemical composition, properties and equivalents can be found in the following tables.

Chemical Composition

The following tables show St52 chemical composition.

St52 steel data sheet – 1, Chemical composition (ladle analysis) according to DIN 17100 and DIN EN 10025: 1993.

      Chemical Composition (ladle analysis), %, ≤
Country (Region) Standard Steel Grade (Steel number) C Si Mn P S N Cu Thickness (d) (mm) Method of deoxidation
Germany DIN 17100: 1980 St52-3 (1.0570) 0.20 0.55 1.60 0.040 0.040 –   ≤ 30 Fully Killded
0.22 30
European Union EN 10025: 1993 S355J2G3 (1.0570) 0.20 0.55 1.60 0.035 0.035 –   ≤ 30
0.22 30
EN 10025-2: 2004 S355J2 (1.0577) 0.20 0.55 1.60 0.025 0.025 – 0.55 ≤ 30
0.22 30

St52 steel data sheet – 2, Chemical composition (product analysis) according to DIN 17100 and DIN EN 10025: 1993.

      Chemical Composition (product analysis), %, ≤
Country (Region) Standard Steel Grade (Steel number) C Si Mn P S N Cu Thickness (d) (mm) Method of deoxidation
Germany DIN 17100: 1980 St52-3 (1.0570) 0.22 0.60 1.70 0.065 0.065 –   ≤ 30 Fully Killded
  0.24 30
European Union EN 10025: 1993 S355J2G3 (1.0570) 0.22 0.60 1.70 0.045 0.045 –   ≤ 30
0.24 30
EN 10025-2: 2004 S355J2 (1.0577) 0.22 0.60 1.70 0.035 0.035 – 0.60 ≤ 30
0.24 30

St52 Steel Properties

Physical Properties

  • Material St 52-3 Density: 7.85 g/cm3
  • Melting point: 1420-1460 °C (2590-2660 °F)

Mechanical Properties

The datasheet below shows St52 steel yield strength, tensile strength, elongation and impact resistance.

  • Structural Steel St52-3 Hardness: ≤180 HB, annealed
  • Charpy impact test (Charpy V-notch, longitudinal) value
    • St52-3U: ≥ 27 J, (thickness: 10≤t≤ 63mm), ≥ 23 J, (thickness: 63
    • St52-3N: ≥ 27 J, (thickness: 10≤t≤ 63mm), ≥ 23 J, (thickness: 63
    • by agreement, (thickness: > 100mm)

Yield Strength

Material St 52-3 Datasheet – 3

  Yield strength (≥ N/mm2); Thickness (d) mm
Steel (Steel number) d≤16 16< d ≤40 40< d ≤63 63< d ≤80 80< d ≤100 >100
St52-3 355 345 335 325 315 by agreement

Tensile Strength

Material St 52-3 Datasheet – 4

  Tensile strength (≥ N/mm2); Thickness (d) mm
Steel (Steel number) d<3 3 ≤ d ≤ 100 >100
St 52-3 515-680 490-630 by agreement

Note: 1MPa = 1N/mm2

Elongation

Material St 52-3 Datasheet – 5

  Elongation (≥, %); Thickness (d), mm
Steel (Steel number) 0.5 ≤d <1 1≤ d <1,5 1,5≤ d <2 2≤ d <2,5 2,5≤ d <3
St52-3U 14 15 16 17 18
St52-3N 12 13 14 15 16
  Elongation (≥, %); Thickness (d), mm
Steel (Steel number) 3 ≤d ≤40 40< d ≤63 63 < d ≤100 >100
St52-3 22 21 20 by agreement
St52-3N 20 19 18

St52 Steel Equivalent Material

Material St52 steel equivalent to American ASTM AISI SAE, European standard EN, British standard BSI, France standard NF, ISO standard, Japanese standard JIS, Chinese GB standard and Indian IS standard. (For reference)

St52 equivalent material
Germany US European Union UK France Japan China India ISO
Standard Steel Standard Steel Standard Steel (Steel number) Standard Steel Standard Steel Standard Steel Standard Steel Standard Steel Standard Steel
DIN 17100: 1980 St 52 ASTM A572/A572M Grade 50 EN 10025-2: 2005 S355             GB/T 1591 Q345; Q355 IS 2062 E350
St 52-3     S355J2 (1.0577)         JIS G3135 SPFC590 Q355C; Q345C     ISO 630-2 S355C
St 52-3U     S355J0 (1.0553) BS 4360 50C NF A35-501 E36-3
