42CrMoS4 (1.7227)
發布者:admin發布時間:2020-11-20 13:40:42

42CrMoS4+QT (1.7227) Steel Properties現貨價格查詢

42CrMoS4 + QT(1.7227)鋼42CrMoS4V材料性能,成分,硬度


The tables below summarize 42crmos4 steel (1.7227 material) properties, and specification including chemical composition, mechanical properties, hardness, heat treatment, etc.

42CrMoS4V Meaning

42CrMoS4V “V” stands for “Vergütet”, which means Quenched and Tempered “+QT”.

Chemical Composition

42crmos4 steel chemical composition is listed in the table below based on cast analysis.

Chemical Composition (cast analysis), %
Standard Steel Grade (Steel Number) C Si, ≤ Mn P, ≤ S Cr Mo
EN 10088-3 42CrMoS4 (1.7227) 0,38-0,45 0,40 0,60-0,90 0,025 0,020-0,040 0,90-1,20 0,15-0,30

Mechanical Properties

42CrMoS4+QT (42CrMoS4V) material mechanical properties are listed in the following tables including yield strength (yield stress), tensile strength, Charpy-V-notch impact, etc.

Notes:

  • 1 MPa = 1 N/mm2
  • 1 GPa = 1 kN/mm2
Mechanical properties at room temperature for 42CrMoS4+QT (42CrMoS4V)
Standard Steel Grade (Steel Number) Upper yield strength, Mpa (ksi), ≥ Tensile strength, Mpa (ksi) Elongation after fracture, %, ≥ Reduction, %, ≥ Charpy-V-notch Impact, J , ≥ Ruling section, diameter (d) or flat thickness (t)
EN 10088-3 42CrMoS4 (1.7227) 900 (130) 1100-1300 (160-188) 10 40 d ≤ 16 mm
t ≤ 8 mm
750 (108) 1000-1200 (145-174) 11 45 35 16 mm < d ≤ 40 mm
8 mm < t ≤ 20 mm
650 (94) 900-1100 (130-160) 12 50 35 40 mm < d ≤ 100 mm
20 mm < t ≤ 60 mm
550 (80) 800-950 (116-138) 13 50 35 100 mm < d ≤ 160 mm
60 mm < t ≤ 100 mm
550 (80) 750-900 (109-130) 14 55 35 160 mm < d ≤ 250 mm
100 mm < t ≤ 160 mm

Rockwell Hardness

Limiting values for the “C” scale Rockwell hardness for 42CrMoS4 (1.7227) material with different hardenability requirements.

Note:

  • +H: “normal hardenability”;
  • +HH and +HL: “with restricted hardenability scatter bands”
Standard Steel Grade (Steel Number) Distance in mm (in.) from quenched end HRC Hardness, (min-max)
+H grade +HH grade +HL grade
EN 10088-3 42CrMoS4 (1.7227) 1,5 (0.059) 53-61 56-61 53-58
3 (0.118) 53-61 56-61 53-58
5 (0.197) 52-61 55-61 52-58
7 (0.276) 51-60 54-60 51-57
9 (0.354) 49-60 52-60 49-56
11 (0.433) 43-59 48-59 43-54
13 (0.512) 40-59 46-59 40-53
15 (0.591) 37-58 44-58 37-51
20 (0.787) 34-56 41-56 34-49
25 (0.984) 32-53 39-53 32-46
30 (1.181) 31-51 38-51 31-44
35 (1.378) 30-48 36-48 30-42
40 (1.575) 30-47 36-47 30-41
45 (1.772) 29-46 35-46 29-40
50 (1.969) 29-45 34-45 29-40
Maximum hardness for products to be supplied in the “treated to improve shearability (+S)” or “soft annealed (+A)” condition
Standard Steel Grade (Steel Number) HBW in +S condition HBW in +A condition
EN 10088-3 42CrMoS4 (1.7227) ≤ 255 ≤ 241
HBW for +S: Depending on the chemical composition of the cast, and on the dimensions, particularly in the case of the +HH-grades, soft annealing may be necessary.

Heat Treatment

Quenching temperature: 820-880 °C (1500-1616°F), austenitizing period: at least 30 min (guide value), quenching agent: oil or water. The temperature at the lower end of the range is generally suitable for hardening in water, and the temperature at the upper end is suitable for hardening in oil.

Tempering temperature: 540-680 °C (1000-1255°F), tempering period: at least 60 min (guide value).

End quench test: 850 ± 5 °C.

Applications

Automotive and aircraft parts with high toughness, such as axles, shafts, gears, tyres, rods, crankshafts, screws, connecting and push rods, etc.

42CrMoS4 Equivalent Material

42CrMoS4V, 42CrMoS4 material (1.7227 steel) equivalent to US ASTM AISI SAE, Germany DIN, British BSI, France NF, ISO, Japanese JIS and Chinese GB standard. (For reference)

42CrMoS4 Equivalent Grade
European Union US China Japan ISO
Standard Grade (Steel Number) Standard Grade Standard Grade Standard Grade Standard Grade
EN 10083-3 42CrMoS4 (1.7227) AISI SAE;
ASTM A29/A29M
4140 GB/T 3077 42CrMo JIS G4053 SCM440 ISO 683-18 42CrMoS4
